CONEXT-RL3000E Сетевой инвертор 3000КВА Xantrex
Характеристики
Тип
Сетевой
Мощность, Вт
7520
Характеристика
Сетевой
По запросу
Цены и наличие по запросу
Цена действительна только для интернет-магазина и может отличаться от цен в розничных магазинах
Описание
SCHNEIDER 3KW CONEXT RL - однофазный сетевой инвертор
Schneider Electric Conext RL преобразователи, специально разработанный для максимизации доходности для широкого круга крыши коттеджей и многоквартирных домах. Богатые MPPT возможностей, высокой эффективности использования энергии, частичное затенение алгоритм и широкий температуры и напряжения рабочий диапазон позволяет добиться максимальной рентабельности инвестиций. Опираясь by Schneider Electric global service инфраструктуры и вопросы управления энергопотреблением, Conext RL серии инверторов, которому можно доверять качество и надежность.Characteristics
| Main | |
|---|---|
| Range of product | Conext RL
|
| Device short name | RL 3000 E
|
| Product or component type | Grid-tie solar inverter
|
| Network number of phases | Single phase
|
| Nominal output power |
3 kVA |
| Complementary | |
| Photovoltaic power | 3.2 kW input power per MPPT
3.2 kW input power for maximal output power |
| Output voltage | 184...276 V AC
230 V AC (nominal) |
| Number of MPPT | 2
|
| Maximum output current | 13.9 A AC
|
| Frequency | 50/60 Hz +/- 5 Hz (output)
|
| Cos phi | 0.8 leading to lagging
|
| Harmonic distortion | < 3 %
|
| Input voltage | 100 V DC at start
90...550 V DC operating <= 550 V DC open circuit 160...500 V DC MPPT |
| Input current per MPPT | <= 10 A
|
| Efficiency | 97.5 % peak
97 % European |
| Power consumption in W | < 1 W night time
|
| Topology | Transformerless
|
| Function available | Standard integrated DC disconnect (optional)
Embedded data logger for 365 days |
| Relay type | Multifunction control relay
|
| Display type | LCD
|
| Messages display capacity | 2 lines of 16 characters
|
| Communication interface | WiFi (optional)
Ethernet (optional) Modbus (RS485) |
| Type of connector | - (IP67 - output)
Multicontact MC4 - input) |
| Type of cooling | Natural convection
|
| Height | 42 cm
|
| Width | 48 cm
|
| Depth | 16 cm
|
| Product weight | 20 kg
|
| Acoustic level | < 40 dBA
|
| Enclosure material |
Aluminium |
| Environment
| |
| IP degree of protection | IP65 (balance)
IP65 (electronic) |
| Ambient air temperature for operation | -20...65 °C
|
| Electromagnetic compatibility | Immunity for industrial environments conforming to EN 61000-6-2
Emission standard for residential, commercial and light-industrial environments conforming to EN 61000-6-3 |
| Standards | VDE 0126
AS 3100 VDE-AR-N 4105 RD 1699 CEI 0-21 IEC 62116 IEC 61727 AS 4777 EN 50438 G83/1 engineering recommendation UTE C 15-712-1 AS 5033 |
| Product certifications | CE marked for low voltage directive 2006/95/EC conforming to 62109-1/62109-2
CE marked for EMC directive 2004/108/EC |
| Operating altitude | < 2000 m
|
| Relative humidity | 4...100 % (condensing)
|
| Environmental characteristic | Stationary use at non-weatherprotected locations, category 4K4H conforming to IEC 60721-3-4
REACH |
